BTU (Pyramax 1)
CFX Source
BTU.PYRAMAX.12345
Current State
Fault Condition
Units Processed Today
Takt Time
Units per Hour
Yield (Today)
Yield (This Hour)
OEE (Today)
OEE (This Hour)
Faults (Today)
Faults (This Hour)
Yield (This Hour)
Yield (Today)
Utilization (This Hour)
Utilization (Today)
Live CFX Feed
0
messages received

{
  "MessageName": "CFX.ResourcePerformance.EnergyConsumed",
  "Version": "1.2",
  "TimeStamp": "2020-10-15T11:00:00.9437165-04:00",
  "UniqueID": "d506c8db-e6db-4a31-ae1b-6a38093174d2",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.EnergyConsumed, CFX",
    "StartTime": "2020-10-15T14:00:00",
    "EndTime": "2020-10-15T14:59:59",
    "EnergyUsed": 100.8,
    "PeakPower": 0.0,
    "MinimumPower": 0.0,
    "MeanPower": 0.0
  }
}
{
  "MessageName": "CFX.ResourcePerformance.EnergyConsumed",
  "Version": "1.2",
  "TimeStamp": "2020-10-15T10:00:00.1255629-04:00",
  "UniqueID": "ce8e94a2-1e1e-4d59-ba3b-b2fa6295bf72",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.EnergyConsumed, CFX",
    "StartTime": "2020-10-15T13:00:00",
    "EndTime": "2020-10-15T13:59:58",
    "EnergyUsed": 67.56,
    "PeakPower": 0.0,
    "MinimumPower": 0.0,
    "MeanPower": 0.0
  }
}
{
  "MessageName": "CFX.ResourcePerformance.FaultOccurred",
  "Version": "1.2",
  "TimeStamp": "2020-10-15T09:20:12.9464642-04:00",
  "UniqueID": "ac924feb-8c12-4381-9bbe-0fc67209428e",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.FaultOccurred, CFX",
    "Fault": {
      "TransactionID": null,
      "Cause": "QualityCheck",
      "Severity": "Alarm",
      "FaultCode": "76000",
      "FaultOccurrenceId": "52d8f0fd-ae83-410f-8d97-211e5b133322",
      "Lane": null,
      "Stage": null,
      "SideLocation": "Unknown",
      "AccessType": "Unknown",
      "Description": "Controller 1 Communication Failure Alarm",
      "DescriptionTranslations": {},
      "OccurredAt": "2020-10-15T13:20:12",
      "DueDateTime": null
    }
  }
}
{
  "MessageName": "CFX.ResourcePerformance.StationStateChanged",
  "Version": "1.2",
  "TimeStamp": "2020-10-15T09:19:53.3646767-04:00",
  "UniqueID": "686aaf04-6ef8-49e5-9569-87ff01d2a3a5",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.StationStateChanged, CFX",
    "OldState": "6500",
    "OldStateDuration": null,
    "NewState": "6000",
    "RelatedFault": null
  }
}
{
  "MessageName": "CFX.Production.OperatorActivated",
  "Version": "1.2",
  "TimeStamp": "2020-10-15T09:19:52.6030456-04:00",
  "UniqueID": "b5c64f0c-ec60-457d-bbe1-22659313379b",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.OperatorActivated, CFX",
    "Operator": {
      "OperatorIdentifier": "Default",
      "ActorType": "Human",
      "LastName": null,
      "FirstName": null,
      "LoginName": null
    }
  }
}
{
  "MessageName": "CFX.Production.RecipeActivated",
  "Version": "1.2",
  "TimeStamp": "2020-10-15T09:19:51.8454913-04:00",
  "UniqueID": "0223efda-b0ef-4316-8fbe-5bee09f62bee",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.RecipeActivated, CFX",
    "RecipeName": "C:\\Wincon\\Demo.rcp",
    "Revision": "39",
    "Lane": null,
    "Stage": null,
    "ExpectedCycleTime": 418.0,
    "ExpectedUnitsPerWorkTransaction": 0.0,
    "NumberOfComponentsPerUnit": 0.0,
    "RecipeStagesInformation": []
  }
}
{
  "MessageName": "CFX.ResourcePerformance.StationOnline",
  "Version": "1.2",
  "TimeStamp": "2020-10-15T09:19:51.445698-04:00",
  "UniqueID": "ac3063a7-93b4-4dda-b6c3-c8fdd0487937",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.StationOnline, CFX",
    "OfflineDuration": "49.21:06:56.4456980"
  }
}
{
  "MessageName": "CFX.ResourcePerformance.StationStateChanged",
  "Version": "1.2",
  "TimeStamp": "2020-09-23T19:12:02.580007-04:00",
  "UniqueID": "c4d17b46-606b-4663-a063-f829fec31e5c",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.StationStateChanged, CFX",
    "OldState": "5000",
    "OldStateDuration": "00:00:01",
    "NewState": "1000",
    "RelatedFault": null
  }
}
{
  "MessageName": "CFX.ResourcePerformance.StationOffline",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:48:50.9563198-04:00",
  "UniqueID": "75cdd514-5064-4866-863f-4b60abd481ce",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.StationOffline, CFX"
  }
}
{
  "MessageName": "CFX.ResourcePerformance.StationStateChanged",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:48:50.9563198-04:00",
  "UniqueID": "2049918d-d7d9-4e84-ab3f-9e2af8f7a6c5",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.StationStateChanged, CFX",
    "OldState": "2200",
    "OldStateDuration": "00:36:18.1200124",
    "NewState": "6500",
    "RelatedFault": null
  }
}
{
  "MessageName": "CFX.Production.UnitsDeparted",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:12:33.5864574-04:00",
  "UniqueID": "0ed9993d-8281-460e-885c-8af817444ea8",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.UnitsDeparted, CFX",
    "PrimaryIdentifier": null,
    "HermesIdentifier": null,
    "UnitCount": 1,
    "Units": [
      {
        "UnitIdentifier": "DERBYCOUNTY",
        "PositionNumber": 0,
        "PositionName": null,
        "X": 0.0,
        "Y": 0.0,
        "Rotation": 0.0,
        "FlipX": false,
        "FlipY": false
      }
    ],
    "Lane": 1
  }
}
{
  "MessageName": "CFX.ResourcePerformance.StationStateChanged",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:12:32.8363074-04:00",
  "UniqueID": "c2d80880-b060-4072-b1a5-6e4bf4eefa28",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.StationStateChanged, CFX",
    "OldState": "1100",
    "OldStateDuration": "00:02:20.2800504",
    "NewState": "2200",
    "RelatedFault": null
  }
}
{
  "MessageName": "CFX.Production.Processing.UnitsProcessed",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:12:15.5813571-04:00",
  "UniqueID": "68355ee5-04d9-44de-9d6f-9a8d2d1a5160",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.Processing.UnitsProcessed, CFX",
    "TransactionId": "b876df97-5114-4cc4-8ea8-d7a1ab08163e",
    "OverallResult": "Succeeded",
    "CommonProcessData": {
      "$type": "CFX.Structures.SolderReflow.ReflowProcessData, CFX",
      "ConveyorSpeed": 312.41832,
      "ConveyorSpeedSetpoint": 312.42,
      "ZoneData": [
        {
          "Zone": {
            "ReflowZoneType": "PreHeat",
            "StageSequence": 1,
            "StageName": "Entrance",
            "StageType": "Work"
          },
          "Setpoints": null,
          "Readings": [
            {
              "SubZone": "WholeZone",
              "ReadingType": "O2",
              "ReadingValue": 90.0
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "1",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 100.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 100.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 99.9
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 12.700000000000001
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 100.0
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 12.700000000000001
            },
            {
              "SubZone": "WholeZone",
              "ReadingType": "ConvectionRate",
              "ReadingValue": 127.0
            },
            {
              "SubZone": "WholeZone",
              "ReadingType": "O2",
              "ReadingValue": 81.9
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "2",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 120.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 120.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 120.0
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 14.600000000000001
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 119.9
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 14.600000000000001
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "3",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 145.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 145.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 144.9
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 18.3
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 145.0
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 17.3
            },
            {
              "SubZone": "WholeZone",
              "ReadingType": "ConvectionRate",
              "ReadingValue": 125.0
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "4",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 165.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 165.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 164.8
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 21.1
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 165.0
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 20.3
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "5",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 175.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 175.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 174.9
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 21.400000000000002
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 174.9
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 21.900000000000002
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "6",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 190.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 190.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 190.0
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 23.400000000000002
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 189.9
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 23.8
            },
            {
              "SubZone": "WholeZone",
              "ReadingType": "ConvectionRate",
              "ReadingValue": 126.0
            },
            {
              "SubZone": "WholeZone",
              "ReadingType": "O2",
              "ReadingValue": 82.300000000000011
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "7",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 200.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 200.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 199.9
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 24.400000000000002
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 200.0
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 24.700000000000003
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "8",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 230.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 230.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 230.20000000000002
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 26.700000000000003
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 230.0
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 28.400000000000002
            },
            {
              "SubZone": "WholeZone",
              "ReadingType": "ConvectionRate",
              "ReadingValue": 126.0
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "9",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 245.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 245.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 245.0
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 29.8
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 245.10000000000002
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 29.900000000000002
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "10",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 255.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 255.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 254.9
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 31.400000000000002
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 255.10000000000002
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 31.3
            },
            {
              "SubZone": "WholeZone",
              "ReadingType": "O2",
              "ReadingValue": 87.100000000000009
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Cool",
            "StageSequence": 1,
            "StageName": "Cool1",
            "StageType": "Work"
          },
          "Setpoints": null,
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 24.1
            },
            {
              "SubZone": "WholeZone",
              "ReadingType": "ConvectionRate",
              "ReadingValue": 126.0
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Cool",
            "StageSequence": 1,
            "StageName": "Cool2",
            "StageType": "Work"
          },
          "Setpoints": null,
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 24.0
            },
            {
              "SubZone": "WholeZone",
              "ReadingType": "ConvectionRate",
              "ReadingValue": 124.0
            },
            {
              "SubZone": "WholeZone",
              "ReadingType": "O2",
              "ReadingValue": 86.300000000000011
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Cool",
            "StageSequence": 1,
            "StageName": "Exit",
            "StageType": "Work"
          },
          "Setpoints": null,
          "Readings": null
        }
      ]
    },
    "UnitProcessData": [
      {
        "UnitIdentifier": "DERBYCOUNTY",
        "UnitPositionNumber": null,
        "UnitResult": "Succeeded",
        "UnitProcessData": null
      }
    ]
  }
}
{
  "MessageName": "CFX.Production.WorkCompleted",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:12:14.830707-04:00",
  "UniqueID": "ceb0d64e-21f6-4c6e-aff7-c50ff5e2eaae",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.WorkCompleted, CFX",
    "TransactionID": "b876df97-5114-4cc4-8ea8-d7a1ab08163e",
    "Result": "Completed",
    "PrimaryIdentifier": null,
    "HermesIdentifier": null,
    "UnitCount": 0,
    "Units": []
  }
}
{
  "MessageName": "CFX.Production.WorkStarted",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:10:16.307007-04:00",
  "UniqueID": "28104298-f2be-4d51-b5c3-e1ceb07181c5",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.WorkStarted, CFX",
    "PrimaryIdentifier": null,
    "HermesIdentifier": null,
    "TransactionID": "b876df97-5114-4cc4-8ea8-d7a1ab08163e",
    "Lane": 1,
    "UnitCount": 1,
    "Units": [
      {
        "UnitIdentifier": "DERBYCOUNTY",
        "PositionNumber": 0,
        "PositionName": null,
        "X": 0.0,
        "Y": 0.0,
        "Rotation": 0.0,
        "FlipX": false,
        "FlipY": false
      }
    ]
  }
}
{
  "MessageName": "CFX.Production.UnitsArrived",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:10:15.556857-04:00",
  "UniqueID": "0fb67ecf-3ad5-4286-8310-a87e5e92c5fe",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.UnitsArrived, CFX",
    "PrimaryIdentifier": null,
    "HermesIdentifier": null,
    "UnitCount": 1,
    "Units": [
      {
        "UnitIdentifier": "DERBYCOUNTY",
        "PositionNumber": 0,
        "PositionName": null,
        "X": 0.0,
        "Y": 0.0,
        "Rotation": 0.0,
        "FlipX": false,
        "FlipY": false
      }
    ],
    "Lane": 1
  }
}
{
  "MessageName": "CFX.Production.UnitsInitialized",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:10:14.806707-04:00",
  "UniqueID": "a8c7bede-c391-4cc8-ba13-182655e4c529",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.UnitsInitialized, CFX",
    "TransactionID": null,
    "PrimaryIdentifier": null,
    "HermesIdentifier": null,
    "WorkOrderIdentifier": null,
    "Units": [
      {
        "UnitIdentifier": "DERBYCOUNTY",
        "PositionNumber": 0,
        "PositionName": null,
        "X": 0.0,
        "Y": 0.0,
        "Rotation": 0.0,
        "FlipX": false,
        "FlipY": false
      }
    ]
  }
}
{
  "MessageName": "CFX.ResourcePerformance.StationStateChanged",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:10:12.556257-04:00",
  "UniqueID": "c6ecf872-fff9-450d-9c05-ba2239653a6e",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.StationStateChanged, CFX",
    "OldState": "2200",
    "OldStateDuration": "00:00:01.5003000",
    "NewState": "1100",
    "RelatedFault": null
  }
}
{
  "MessageName": "CFX.ResourcePerformance.StationStateChanged",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:10:11.055957-04:00",
  "UniqueID": "91a7eb59-e80d-4313-bbe4-0bd23bd297ff",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.StationStateChanged, CFX",
    "OldState": "4500",
    "OldStateDuration": "00:02:26.2797501",
    "NewState": "2200",
    "RelatedFault": null
  }
}
{
  "MessageName": "CFX.Sensor.Identification.IdentifiersRead",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:09:01.2915069-04:00",
  "UniqueID": "18449ed4-a0d1-4acb-9f3b-90329557df0e",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Sensor.Identification.IdentifiersRead, CFX",
    "PrimaryIdentifier": "DERBYCOUNTY",
    "HermesIdentifier": null,
    "Units": null
  }
}
{
  "MessageName": "CFX.ResourcePerformance.StationParametersModified",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:08:45.5383569-04:00",
  "UniqueID": "a99a23a0-aedb-4459-8b0f-d4b2ebcc754b",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.StationParametersModified, CFX",
    "ModifiedParameters": [
      {
        "$type": "CFX.Structures.GenericParameter, CFX",
        "Name": "Barcode Configuration",
        "Value": "Saved"
      }
    ]
  }
}
{
  "MessageName": "CFX.ResourcePerformance.StationParametersModified",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:07:55.2783069-04:00",
  "UniqueID": "eaa2b8d4-b7b6-4fe1-a5b6-81a6b3e4cfa4",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.StationParametersModified, CFX",
    "ModifiedParameters": [
      {
        "$type": "CFX.Structures.GenericParameter, CFX",
        "Name": "Atmosphere Monitoring Configuration",
        "Value": "Saved"
      }
    ]
  }
}
{
  "MessageName": "CFX.Production.RecipeModified",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:07:54.5281569-04:00",
  "UniqueID": "37d109a0-bd75-4d5e-9db9-fa8ad57e6406",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.RecipeModified, CFX",
    "RecipeName": "C:\\Wincon\\Barcode_Test.rcp",
    "Revision": "13",
    "ModifiedBy": {
      "OperatorIdentifier": "fs - Paul Edgington",
      "ActorType": "Human",
      "LastName": null,
      "FirstName": null,
      "LoginName": null
    },
    "Reason": "Unspecified",
    "Notes": null
  }
}
{
  "MessageName": "CFX.ResourcePerformance.StationStateChanged",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:07:44.7762069-04:00",
  "UniqueID": "c044ea45-1988-469e-acdf-ef78fd52504f",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.StationStateChanged, CFX",
    "OldState": "2200",
    "OldStateDuration": "00:00:58.5117000",
    "NewState": "4500",
    "RelatedFault": null
  }
}
{
  "MessageName": "CFX.Production.RecipeActivated",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:07:44.0260569-04:00",
  "UniqueID": "64f615df-c8a4-4605-9df5-e6b4dc3993be",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.RecipeActivated, CFX",
    "RecipeName": "C:\\Wincon\\Barcode_Test.rcp",
    "Revision": "12",
    "Lane": null,
    "Stage": null,
    "ExpectedCycleTime": 112.0,
    "ExpectedUnitsPerWorkTransaction": 0.0,
    "NumberOfComponentsPerUnit": 0.0,
    "RecipeStagesInformation": []
  }
}
{
  "MessageName": "CFX.Production.RecipeModified",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:07:42.5257569-04:00",
  "UniqueID": "3eaf9c32-d96e-40b0-8666-687efce02405",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.RecipeModified, CFX",
    "RecipeName": "C:\\Wincon\\Barcode_Test.rcp",
    "Revision": "12",
    "ModifiedBy": {
      "OperatorIdentifier": "fs - Paul Edgington",
      "ActorType": "Human",
      "LastName": null,
      "FirstName": null,
      "LoginName": null
    },
    "Reason": "Unspecified",
    "Notes": null
  }
}
{
  "MessageName": "CFX.Production.UnitsDeparted",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:06:47.7648069-04:00",
  "UniqueID": "e582a654-a660-4fd2-ab9c-61c18406edb9",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.UnitsDeparted, CFX",
    "PrimaryIdentifier": null,
    "HermesIdentifier": null,
    "UnitCount": 1,
    "Units": [
      {
        "UnitIdentifier": "AABBXXZZ",
        "PositionNumber": 0,
        "PositionName": null,
        "X": 0.0,
        "Y": 0.0,
        "Rotation": 0.0,
        "FlipX": false,
        "FlipY": false
      }
    ],
    "Lane": 1
  }
}
{
  "MessageName": "CFX.ResourcePerformance.StationStateChanged",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:06:46.2645069-04:00",
  "UniqueID": "bc08f245-d322-47de-aa4f-81971f24a8c6",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.StationStateChanged, CFX",
    "OldState": "1100",
    "OldStateDuration": "00:02:19.5304005",
    "NewState": "2200",
    "RelatedFault": null
  }
}
{
  "MessageName": "CFX.Production.Processing.UnitsProcessed",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:06:29.0100567-04:00",
  "UniqueID": "1e4a6f07-b4e4-4d7f-b0cb-7cfddf22078f",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.Processing.UnitsProcessed, CFX",
    "TransactionId": "cc057fe6-54ff-4b7f-bea9-435446a58be2",
    "OverallResult": "Succeeded",
    "CommonProcessData": {
      "$type": "CFX.Structures.SolderReflow.ReflowProcessData, CFX",
      "ConveyorSpeed": 312.38304,
      "ConveyorSpeedSetpoint": 312.42,
      "ZoneData": [
        {
          "Zone": {
            "ReflowZoneType": "PreHeat",
            "StageSequence": 1,
            "StageName": "Entrance",
            "StageType": "Work"
          },
          "Setpoints": null,
          "Readings": null
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "1",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 100.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 100.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 100.0
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 12.600000000000001
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 100.0
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 12.100000000000001
            },
            {
              "SubZone": "WholeZone",
              "ReadingType": "ConvectionRate",
              "ReadingValue": 125.0
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "2",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 120.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 120.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 119.9
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 15.0
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 120.0
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 14.5
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "3",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 145.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 145.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 145.1
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 17.3
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 145.1
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 17.900000000000002
            },
            {
              "SubZone": "WholeZone",
              "ReadingType": "ConvectionRate",
              "ReadingValue": 125.0
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "4",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 165.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 165.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 164.9
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 20.3
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 165.0
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 20.3
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "5",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 175.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 175.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 175.0
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 21.900000000000002
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 175.0
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 21.3
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "6",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 190.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 190.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 190.10000000000002
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 23.5
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 190.0
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 23.3
            },
            {
              "SubZone": "WholeZone",
              "ReadingType": "ConvectionRate",
              "ReadingValue": 127.0
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "7",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 200.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 200.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 200.0
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 24.3
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 200.10000000000002
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 24.3
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "8",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 230.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 230.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 230.0
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 28.1
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 230.10000000000002
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 28.0
            },
            {
              "SubZone": "WholeZone",
              "ReadingType": "ConvectionRate",
              "ReadingValue": 125.0
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "9",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 245.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 245.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 244.70000000000002
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 31.1
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 245.0
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 30.5
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "10",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 255.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 255.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 256.5
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 24.3
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 255.10000000000002
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 31.400000000000002
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Cool",
            "StageSequence": 1,
            "StageName": "Cool1",
            "StageType": "Work"
          },
          "Setpoints": null,
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 24.0
            },
            {
              "SubZone": "WholeZone",
              "ReadingType": "ConvectionRate",
              "ReadingValue": 126.0
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Cool",
            "StageSequence": 1,
            "StageName": "Cool2",
            "StageType": "Work"
          },
          "Setpoints": null,
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 24.1
            },
            {
              "SubZone": "WholeZone",
              "ReadingType": "ConvectionRate",
              "ReadingValue": 125.0
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Cool",
            "StageSequence": 1,
            "StageName": "Exit",
            "StageType": "Work"
          },
          "Setpoints": null,
          "Readings": null
        }
      ]
    },
    "UnitProcessData": [
      {
        "UnitIdentifier": "AABBXXZZ",
        "UnitPositionNumber": null,
        "UnitResult": "Succeeded",
        "UnitProcessData": null
      }
    ]
  }
}
{
  "MessageName": "CFX.Production.WorkCompleted",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:06:28.2594066-04:00",
  "UniqueID": "869508bd-6b95-427d-96a1-90c07560a8d0",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.WorkCompleted, CFX",
    "TransactionID": "cc057fe6-54ff-4b7f-bea9-435446a58be2",
    "Result": "Completed",
    "PrimaryIdentifier": null,
    "HermesIdentifier": null,
    "UnitCount": 0,
    "Units": []
  }
}
{
  "MessageName": "CFX.Production.WorkStarted",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:04:28.9855566-04:00",
  "UniqueID": "34bca1fd-c3e1-46c3-9897-f39b5239d045",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.WorkStarted, CFX",
    "PrimaryIdentifier": null,
    "HermesIdentifier": null,
    "TransactionID": "cc057fe6-54ff-4b7f-bea9-435446a58be2",
    "Lane": 1,
    "UnitCount": 1,
    "Units": [
      {
        "UnitIdentifier": "AABBXXZZ",
        "PositionNumber": 0,
        "PositionName": null,
        "X": 0.0,
        "Y": 0.0,
        "Rotation": 0.0,
        "FlipX": false,
        "FlipY": false
      }
    ]
  }
}
{
  "MessageName": "CFX.Production.UnitsArrived",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:04:28.2349065-04:00",
  "UniqueID": "4fcbbf4d-913f-42ee-8fcb-595ccc68395d",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.UnitsArrived, CFX",
    "PrimaryIdentifier": null,
    "HermesIdentifier": null,
    "UnitCount": 1,
    "Units": [
      {
        "UnitIdentifier": "AABBXXZZ",
        "PositionNumber": 0,
        "PositionName": null,
        "X": 0.0,
        "Y": 0.0,
        "Rotation": 0.0,
        "FlipX": false,
        "FlipY": false
      }
    ],
    "Lane": 1
  }
}
{
  "MessageName": "CFX.Production.UnitsInitialized",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:04:27.4847565-04:00",
  "UniqueID": "f9e0538a-e75c-48da-ad91-6c57848461d2",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.UnitsInitialized, CFX",
    "TransactionID": null,
    "PrimaryIdentifier": null,
    "HermesIdentifier": null,
    "WorkOrderIdentifier": null,
    "Units": [
      {
        "UnitIdentifier": "AABBXXZZ",
        "PositionNumber": 0,
        "PositionName": null,
        "X": 0.0,
        "Y": 0.0,
        "Rotation": 0.0,
        "FlipX": false,
        "FlipY": false
      }
    ]
  }
}
{
  "MessageName": "CFX.ResourcePerformance.StationStateChanged",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:04:26.7341064-04:00",
  "UniqueID": "19affb11-aa23-420e-afab-3adab4734144",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.StationStateChanged, CFX",
    "OldState": "2200",
    "OldStateDuration": "00:03:21.8018523",
    "NewState": "1100",
    "RelatedFault": null
  }
}
{
  "MessageName": "CFX.Sensor.Identification.IdentifiersRead",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:03:40.9749564-04:00",
  "UniqueID": "d3a2b8e0-6819-4a59-a3d9-174708ab5190",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Sensor.Identification.IdentifiersRead, CFX",
    "PrimaryIdentifier": "AABBXXZZ",
    "HermesIdentifier": null,
    "Units": null
  }
}
{
  "MessageName": "CFX.ResourcePerformance.StationParametersModified",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:03:27.4722564-04:00",
  "UniqueID": "176a75f5-585f-436a-9154-a4479dc1bdc7",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.StationParametersModified, CFX",
    "ModifiedParameters": [
      {
        "$type": "CFX.Structures.GenericParameter, CFX",
        "Name": "Furnace Layout",
        "Value": "Saved"
      }
    ]
  }
}
{
  "MessageName": "CFX.Production.UnitsDeparted",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:01:06.4330542-04:00",
  "UniqueID": "add6b979-c532-475c-a267-0ed53088ad1b",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.UnitsDeparted, CFX",
    "PrimaryIdentifier": null,
    "HermesIdentifier": null,
    "UnitCount": 1,
    "Units": [
      {
        "UnitIdentifier": "MyFirstPCB12345XXZZ",
        "PositionNumber": 0,
        "PositionName": null,
        "X": 0.0,
        "Y": 0.0,
        "Rotation": 0.0,
        "FlipX": false,
        "FlipY": false
      }
    ],
    "Lane": 1
  }
}
{
  "MessageName": "CFX.ResourcePerformance.StationStateChanged",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:01:04.9322541-04:00",
  "UniqueID": "6ade4aa8-ab1d-45cd-8f1b-b80034968186",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.StationStateChanged, CFX",
    "OldState": "1100",
    "OldStateDuration": "00:02:19.5354015",
    "NewState": "2200",
    "RelatedFault": null
  }
}
{
  "MessageName": "CFX.Production.Processing.UnitsProcessed",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:00:46.9261536-04:00",
  "UniqueID": "1537a0b7-22d2-4305-9f6b-13f300bd209e",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.Processing.UnitsProcessed, CFX",
    "TransactionId": "d2e72b59-96fb-4351-8d90-64a3dd7a612f",
    "OverallResult": "Succeeded",
    "CommonProcessData": {
      "$type": "CFX.Structures.SolderReflow.ReflowProcessData, CFX",
      "ConveyorSpeed": 312.35466,
      "ConveyorSpeedSetpoint": 312.42,
      "ZoneData": [
        {
          "Zone": {
            "ReflowZoneType": "PreHeat",
            "StageSequence": 1,
            "StageName": "Entrance",
            "StageType": "Work"
          },
          "Setpoints": null,
          "Readings": null
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "1",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 100.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 100.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 99.9
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 12.4
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 99.9
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 12.5
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "2",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 120.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 120.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 119.9
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 14.9
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 119.9
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 14.9
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "3",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 145.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 145.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 141.8
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 16.0
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 145.20000000000002
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 18.0
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "4",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 165.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 165.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 164.70000000000002
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 21.200000000000003
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 165.0
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 20.3
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "5",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 175.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 175.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 175.0
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 21.400000000000002
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 175.0
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 19.700000000000003
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "6",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 190.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 190.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 190.0
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 23.8
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 190.10000000000002
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 22.8
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "7",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 200.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 200.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 201.3
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 16.1
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 200.10000000000002
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 24.1
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "8",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 230.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 230.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 230.0
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 28.0
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 228.70000000000002
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 12.100000000000001
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "9",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 245.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 245.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 241.4
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 31.700000000000003
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 244.4
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 29.400000000000002
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "Reflow",
            "StageSequence": 1,
            "StageName": "10",
            "StageType": "Work"
          },
          "Setpoints": [
            {
              "SubZone": "Top",
              "SetpointType": "Temperature",
              "Setpoint": 255.0
            },
            {
              "SubZone": "Bottom",
              "SetpointType": "Temperature",
              "Setpoint": 255.0
            }
          ],
          "Readings": [
            {
              "SubZone": "Top",
              "ReadingType": "Temperature",
              "ReadingValue": 254.4
            },
            {
              "SubZone": "Top",
              "ReadingType": "PowerLevel",
              "ReadingValue": 31.0
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "Temperature",
              "ReadingValue": 259.40000000000003
            },
            {
              "SubZone": "Bottom",
              "ReadingType": "PowerLevel",
              "ReadingValue": 30.0
            }
          ]
        },
        {
          "Zone": {
            "ReflowZoneType": "PreHeat",
            "StageSequence": 1,
            "StageName": "Entrance",
            "StageType": "Work"
          },
          "Setpoints": null,
          "Readings": null
        },
        {
          "Zone": {
            "ReflowZoneType": "Cool",
            "StageSequence": 1,
            "StageName": "Exit",
            "StageType": "Work"
          },
          "Setpoints": null,
          "Readings": null
        }
      ]
    },
    "UnitProcessData": [
      {
        "UnitIdentifier": "MyFirstPCB12345XXZZ",
        "UnitPositionNumber": null,
        "UnitResult": "Succeeded",
        "UnitProcessData": null
      }
    ]
  }
}
{
  "MessageName": "CFX.Production.WorkCompleted",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:00:46.1760036-04:00",
  "UniqueID": "089a5bdf-f383-46ee-806d-bbdc8081c20a",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.WorkCompleted, CFX",
    "TransactionID": "d2e72b59-96fb-4351-8d90-64a3dd7a612f",
    "Result": "Completed",
    "PrimaryIdentifier": null,
    "HermesIdentifier": null,
    "UnitCount": 0,
    "Units": []
  }
}
{
  "MessageName": "CFX.ResourcePerformance.EnergyConsumed",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T09:00:00.4123527-04:00",
  "UniqueID": "12447fc4-1c6e-4251-bd33-cf4e2da478f0",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.EnergyConsumed, CFX",
    "StartTime": "2020-09-03T12:00:00",
    "EndTime": "2020-09-03T12:59:59",
    "EnergyUsed": 8401.98,
    "PeakPower": 0.0,
    "MinimumPower": 0.0,
    "MeanPower": 0.0
  }
}
{
  "MessageName": "CFX.Production.WorkStarted",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T08:58:47.6473026-04:00",
  "UniqueID": "ef5d0868-ba17-49b4-8cc8-254fbd136c6f",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.WorkStarted, CFX",
    "PrimaryIdentifier": null,
    "HermesIdentifier": null,
    "TransactionID": "d2e72b59-96fb-4351-8d90-64a3dd7a612f",
    "Lane": 1,
    "UnitCount": 1,
    "Units": [
      {
        "UnitIdentifier": "MyFirstPCB12345XXZZ",
        "PositionNumber": 0,
        "PositionName": null,
        "X": 0.0,
        "Y": 0.0,
        "Rotation": 0.0,
        "FlipX": false,
        "FlipY": false
      }
    ]
  }
}
{
  "MessageName": "CFX.Production.UnitsArrived",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T08:58:46.8971526-04:00",
  "UniqueID": "9063a101-4354-440a-8b26-6971a582f24c",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.UnitsArrived, CFX",
    "PrimaryIdentifier": null,
    "HermesIdentifier": null,
    "UnitCount": 1,
    "Units": [
      {
        "UnitIdentifier": "MyFirstPCB12345XXZZ",
        "PositionNumber": 0,
        "PositionName": null,
        "X": 0.0,
        "Y": 0.0,
        "Rotation": 0.0,
        "FlipX": false,
        "FlipY": false
      }
    ],
    "Lane": 1
  }
}
{
  "MessageName": "CFX.Production.UnitsInitialized",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T08:58:46.1470026-04:00",
  "UniqueID": "9bff6016-1162-40d8-8d07-4ef7de84246c",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.UnitsInitialized, CFX",
    "TransactionID": null,
    "PrimaryIdentifier": null,
    "HermesIdentifier": null,
    "WorkOrderIdentifier": null,
    "Units": [
      {
        "UnitIdentifier": "MyFirstPCB12345XXZZ",
        "PositionNumber": 0,
        "PositionName": null,
        "X": 0.0,
        "Y": 0.0,
        "Rotation": 0.0,
        "FlipX": false,
        "FlipY": false
      }
    ]
  }
}
{
  "MessageName": "CFX.ResourcePerformance.StationStateChanged",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T08:58:45.3968526-04:00",
  "UniqueID": "2f0934cb-3264-4869-829e-cd49b808e4b0",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.StationStateChanged, CFX",
    "OldState": "2200",
    "OldStateDuration": "00:05:57.8135347",
    "NewState": "1100",
    "RelatedFault": null
  }
}
{
  "MessageName": "CFX.Sensor.Identification.IdentifiersRead",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T08:58:25.8929526-04:00",
  "UniqueID": "13ba7152-d425-47bf-a26f-e5abb1f7a8ea",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Sensor.Identification.IdentifiersRead, CFX",
    "PrimaryIdentifier": "MyFirstPCB12345XXZZ",
    "HermesIdentifier": null,
    "Units": null
  }
}
{
  "MessageName": "CFX.Production.RecipeActivated",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T08:58:03.3884526-04:00",
  "UniqueID": "42c21f61-c59e-41a4-aaa1-fee6886fad06",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.RecipeActivated, CFX",
    "RecipeName": "C:\\Wincon\\Barcode_Test.rcp",
    "Revision": "11",
    "Lane": null,
    "Stage": null,
    "ExpectedCycleTime": 112.0,
    "ExpectedUnitsPerWorkTransaction": 0.0,
    "NumberOfComponentsPerUnit": 0.0,
    "RecipeStagesInformation": []
  }
}
{
  "MessageName": "CFX.Production.RecipeModified",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T08:58:01.8881526-04:00",
  "UniqueID": "43e684fb-4e94-4faf-b874-54988128025e",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.Production.RecipeModified, CFX",
    "RecipeName": "C:\\Wincon\\Barcode_Test.rcp",
    "Revision": "11",
    "ModifiedBy": {
      "OperatorIdentifier": "fs - Paul Edgington",
      "ActorType": "Human",
      "LastName": null,
      "FirstName": null,
      "LoginName": null
    },
    "Reason": "Unspecified",
    "Notes": null
  }
}
{
  "MessageName": "CFX.ResourcePerformance.CalibrationPerformed",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T08:56:16.1060004-04:00",
  "UniqueID": "9186e260-3065-41e0-ba6e-14ab5e8ca42d",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.CalibrationPerformed, CFX",
    "Calibration": {
      "CalibrationCode": "Analog Inputs",
      "CalibrationType": "General",
      "Comments": "User Saved Calibration to Controller 2"
    }
  }
}
{
  "MessageName": "CFX.ResourcePerformance.StationParametersModified",
  "Version": "1.2",
  "TimeStamp": "2020-09-03T08:56:15.3558504-04:00",
  "UniqueID": "cab2fe5d-272e-4224-acc3-b7455d0128cd",
  "Source": "BTU.PYRAMAX.12345",
  "Target": null,
  "RequestID": null,
  "MessageBody": {
    "$type": "CFX.ResourcePerformance.StationParametersModified, CFX",
    "ModifiedParameters": [
      {
        "$type": "CFX.Structures.GenericParameter, CFX",
        "Name": "Embedded Controller Calibration",
        "Value": "Saved"
      }
    ]
  }
}
